p. 17/48
û
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using this information for any purpose
other than the use of the products or the execution of the project to which it refers and from communicating it to third parties without prior written agreement of Automatic
Systems. The document is subject to change without notice.
TRS373-MT-EN-01
ü
Insert the connector into the connecting rod of the bolt
(not shown) and hold it in place with the connector clip.
Make sure the spring coils do not touch each other
when the electromagnet is powered (adjust connector
position if necessary).
In the OPTIONS menu of the control board, set the
ELECTROMAGNET parameter to A4 (or B4 according to
the direction of passage).
p. 17/48
