Temperature
Counter 1
Counter 2
Reset counter 2
No. Authoris. A
No. Authoris. B
App. Status
Pass A State
Pass B State
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using this information for any purpose
other than the use of the products or the execution of the project to which it refers and from communicating it to third parties without prior written agreement of Automatic
Systems. The document is subject to change without notice.
TRS373-MT-EN-01
Parameter Value
Short Circuit
Save Mem1
Save Mem2
Load Default
Load Mem1
Load Mem2
Time Adjust
Access Level Chg
Download Chg Lv1
Download Chg Lv2
Download Chg Lv3
Reset Counters
In Service
Out Of Service
Emergency
Test
Maintenance
Default LSA
Default LSB
Yes
Evacuation
Test
Maintenance
In Service.
Out of Service
Locked
Free
Controlled
Locked
Free
Description
Detection of short-circuit at the digital outputs.
Manual saving of values to Memory 1.
Manual saving of values to Memory 2.
Loading of default values.
Manual loading of values from Memory 1.
Manual loading of values from Memory 2.
Change of date and time.
Change of access level (OPTION  Code).
Level 1 modification to program.
Level 2 modification to program.
Level 3 modification to program.
Zeroing of Counter 2.
Apparatus in service.
Apparatus out of service.
Apparatus in Evacuation mode.
Apparatus in Test mode.
Apparatus in Maintenance mode.
Limit switch A defect. The turnstile remains in service.
Limit switch B defect. The turnstile remains in service.
Displays temperature within the casing.
Total number of passages in directions A and B.
Number of passages in directions A and B since last
reset to zero.
Zeroing of counter 2.
Number of authorisations by the validating device in
direction A.
Number of authorisations by the validating device in
direction B.
Indicates the current status of the apparatus.
Free passage in both directions.
Apparatus in test mode.
Apparatus in maintenance mode.
Apparatus in service (configuration in OPERATION group).
Apparatus locked in both directions: command received
at input DI5.
Indicates the status of the apparatus when it is operation,
for direction A (configuration in the OPERATION group).
Obstacle locked: passage in this direction is impossible.
Obstacle unlocked: passage in this direction is free and
not controlled.
Obstacle is unlocked after authorisation by the reader.
Same as Pass A State, for direction B.
