GROUP
TIMINGS
OUTPUT FUNCTIONS Relay 1
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using this information for any purpose
other than the use of the products or the execution of the project to which it refers and from communicating it to third parties without prior written agreement of Automatic
Systems. The document is subject to change without notice.
TRS373-MT-EN-01
Parameter Value
Controlled
No Passage
Passage Info
No Pass Info
Fraud Info
LED Lighting
LSB Error
LSA Error
Fraud AB
Fraud B
Fraud A
No Passage B
No Passage A
Pass B IP NC
Pass E IP NO
Pass A IP NC
Pass A IP NO
Passage B NC
Passage B NO
Passage A NC
Passage A NO
Red Fct Pict B
Grn Fct Pict B
Red Fct Pict A
Grn Fct Pict A
Red Ori Pict B
Grn Ori Pict B
Red Ori Pict A
Grn Ori Pict A
Solenoid B
Solenoid A
None
Relay 2
Description
Delay allowed for user to pass through the turnstile
(= time allowed for the obstacle to reach the limit switch
after an Open command).
Duration of the passage information impulse.
Duration of the no-passage information impulse.
Duration of the fraud information impulse.
Each output can provide one of the following information
elements:
LED lighting activated by the light sensor.
Direction B limit switch sensor has not been reached
before the no-passage time-out.
Direction A limit switch sensor has not been reached
before the no-passage time-out.
Limit switch activated without prior OPEN command.
Direction B limit switch detection not preceded by an
Open command.
Direction A limit switch detection not preceded by an
Open command.
No detection on time limit switch within the time limit
following an Open command in direction B.
No detection on time limit switch within the time limit
following an Open command in direction A.
Passage in direction B in progress (signal NC).
Passage in direction B in progress (signal NO).
Passage in direction A in progress (signal NC).
Passage in direction A in progress (signal NO).
Passage in direction B completed (signal NC).
Passage in direction B completed (signal NO).
Passage in direction A completed (signal NC).
Passage in direction A completed (signal NO).
Direction B Red function pictogram is lit.
Direction B Green function pictogram is lit.
Direction A Red function pictogram is lit.
Direction A Green function pictogram is lit.
Direction B Red orientation pictogram is lit.
Direction B Green orientation pictogram is lit.
Direction A Red orientation pictogram is lit.
Direction A Green orientation pictogram is lit.
Control of electromagnet in direction B.
Control of electromagnet in direction A.
No signal.
Same as Relay 1
