2) The figure 2a shows the shape of the electrical
i
The voltage on the connector is of the S.E.L.V. (very low safety voltage
according to the definition of EN60950-1).
The element defined as "reference key
the other) must be set in a specific position, in order to correctly assemble the
interface kit (see the following figures).
3) Insert the base of the interface kit until is stopped
(that has a greater extension with respect to
Chapter 6  INSTALLATION OF PLUG HEAD
connector.
Reference key
(Figure 2b)
2a
2b
