6.2 System with Star lock connection
6.2.1 Combinations without depth extensions
BASE
3TJ6SDI000
3TJ6SDI000
3TJ6SDI000
(*) Nota: Compatibile con capsule MARPOSS MBG/DIATEST/HEXACON.
ADAPTER
2TIMSM3501*
2TIMSM3505
2TIMSM3502
2TIMSM3503
2TIMSM3504
2TIMSM0600
2TIMSM1000
Chapter 6  INSTALLATION OF PLUG HEAD
APPLICATION
for plug head with M3.5 thread and 3 ≤
for plug head with M3.5 thread and 4 ≤
for plug head with M3.5 thread and 4.5 ≤
for plug head with M3.5 thread and 5.5 ≤
for plug head with M3.5 thread and 7.5 ≤
M3,5 x 0,35
for plug head with M6 thread and 9.5 ≤ ø < 26
M6 x 0,75
for plug head with M10 thread (DIA/HEX)
M10 x 1
ø
< 4
ø
< 4.5
ø
< 5.5
ø
< 7.5
ø
< 9.5
