2.2.3 Stand charger description
Figure 2-4. Stand charger description.
The I-Wave2/Wave2 stand chargers are designed to safely hold the gauge handle
with its plug mounted.
At the same time it charges the gauge handle internal battery through a wireless power
system.
The supports are equipped with a system for detecting foreign objects and recognizing
the gauge handle.
Charging starts when the electromagnetic circuit between the handle and the support
closes. This occurs when the metal plate on the back of the gauge handle comes in
contact with the support.
WARNING
If the metal plate is NOT present, charging does not take place.
Two LEDs (A) are provided to indicate the operating status (see section 4.3.1).
