Access Power Rectifiers (APR24-3G/APR48-3G)

Powerware Data-Voice-Video Power Solutions can be fitted with either 24V or 48V Access
Power Rectifiers (APR24-3G/APR48-3G). All rectifiers are fan-cooled and hot-pluggable.
See Specifications on page 59 for further information.
See Troubleshooting on page 44 for details of rectifier alarms.
Copyright © 2005-2007 Eaton Corporation. All Rights Reserved.
IPN 997-00012-54A
Power On LED (Green)
Minor Alarm LED (Yellow)
Major Alarm LED (Red)
Serial Number label
Retaining Screw. Tighten to 1.5Nm (13.3
inch-pounds).
