Adding a Load Fuse

Step 1 - Access the fuses
Step 2 - Fit new fuse base and link
Step 3 - Fit a fuse fail detect wire
Step 4 - Connect load cable (if required)
Procedure complete

Replacing the System Controller

The SC200 system controller can be replaced without switching off the DV2-3G and
disconnecting the equipment it powers.
Before you start, you need
A PC with the latest version of DCTools software installed.
•
A copy of the appropriate SC200 configuration file, which can be one of the following:
•
the old configuration file, or
•
a backed-up configuration file, or
•
a customized standard (master) configuration file
•
A USB A/B cable.
•
A replacement SC200 system controller.
•
Step 1 - Backup the configuration file of the old SC200
The load fuses are located in the distribution space. See diagram on
1
page 2.
Bolt the new fuse base to the live bus.
1
Tighten the bolt according to the Standard Torque Settings on page 58.
2
Place a spare fuse fail detect wire into the top terminal of the fuse.
1
Tighten the top terminal.
2
Follow the procedure on page 22.
If the old SC200 is still operational use DCTools to backup its configuration file.
Refer to Backup and Restore in the System Controller Operation Handbook (see
Related Information).
Copyright © 2005-2007 Eaton Corporation. All Rights Reserved.
IPN 997-00012-54A July 2007
