Order of Tasks

Complete the installation tasks in the following order:
Task Description
1 Check the AC Supply and Earthing
2 Fixing the Power System Cabinet(s)
3 Connect the DC Output to Earth
4 Connect the DC Load Cables
5 Connect Battery Cables (if required)
6 Install the Batteries
7 Mount the Battery Temperature Sensor
8 Connect External Current Sensors/Shunts (if required)
9 Connect Input/Output Cabling (if required)
10 Connect Additional Input/Output (if required)
11 Connect to AC Supply
For installation of external communications refer to Communications Options in the system
controller Operation Handbook (see Related Information on page i).

Task 1 - Check the AC Supply and Earthing

It is important that the AC supply for the Data-Voice-Video Power Solutions DC power
system includes the correct levels of protection.
Step 1 - Check transient voltage protection at the site
Confirm that there is a transient protection plan (compliant with IEC
1
61643-12) for the site.
For more information refer to Transient Protection on page 73.
If necessary, install suitable transient protection.
2
Copyright © 2005-2007 Eaton Corporation. All Rights Reserved.
IPN 997-00012-54A July 2007
Installation
Reference
See details on page 15
See details on page 18
See details on page 20
See details on page 22
See details on page 23
See details on page 25
See details on page 28
See details on page 29
See details on page 29
See details on page 30
See details on page 31
15
