3G-SC200 Data-Voice-Video Power Solutions Installation Guide
Problem
System has no DC output
(rectifiers are on)
System has no battery input
46
Possible Cause
Load fuse or MCB open.
LVD has disconnected load.
Battery fuse or MCB open.
LVD has disconnected battery.
Copyright © 2005-2007 Eaton Corporation. All Rights Reserved.
IPN 997-00012-54A
Required Action
Check the load fuses or MCBs.
Use DCTools/Web to check LVD is
enabled and set to correct values.
(LVD status LED on the I/O board is
on when LVD is connected.)
Check that the I/O board is
connected (Power LED is on).
Check that the LVD control and
power cables are connected. See
Connections on page 7.
Check the connections from the live
bus to the LVD.
Check LVD contactor coil.
Replace I/O board.
Check the battery fuses or MCBs.
Use DCTools/Web to check LVD is
enabled and set to correct values.
(LVD status LED on the I/O board is
on when LVD is connected.)
Check that the I/O board is
connected (Power LED is on).
Check that the LVD control and
power cables are connected. See
Connections on page 7.
Check the connections from the
battery bus to the LVD.
Check LVD contactor coil.
Replace I/O board.
July 2007
