Parameter
Float Voltage
Battery Capacity
Cells Per String
Temperature
Compensation
Low Voltage
Disconnect (LVD)
* Refer to the System Controller Operation Handbook for navigation details (see
Related Information on page i).
Other configuration settings can be changed after all Start-Up tasks are complete. Refer to the
System Controller Operation Handbook (see Related Information on page i) for details on
how to customize the system's configuration.

Task 5 - Apply DC Power to Battery and Load

Reverse Polarity
•
Always check that the battery cables have been terminated to the correct system polarity
BEFORE connecting the batteries or closing the battery disconnect device. Connecting batteries
to the DC power system with incorrect system polarity will damage the rectifiers and void all
warranty claims.
Step 1 - Check DC voltage and polarity
Step 2 - Connect batteries
Action
Set to the value recommended by
the battery manufacturer.
Set to the rated 10 hour capacity of
the installed battery strings. Zero
means no battery is installed.
Set to the number of cells in each
battery string.
Enable (if required) and check the
settings.
Enable (if LVD installed) and check
the settings.
Check the DC output voltage and polarity of the power system and the
battery string(s).
If connecting multiple battery strings then check the individual strings
1
are of similar voltage.
Switch on all Battery MCB(s) and/or fit the battery fuses.
2
Check the Battery Fuse Fail alarm clears.
3
All Battery MCBs (including any unused MCBs) must be switched on
to clear the alarm.
Check the battery current. The actual value depends on the state of
4
charge of the batteries.
Copyright © 2005-2007 Eaton Corporation. All Rights Reserved.
IPN 997-00012-54A
SC200 Navigation*
Menu > Voltage Controls >
Voltage Control
Menu > Settings > Battery
Menu > Settings > Battery
Menu > Voltage Controls >
Temperature Compensation
Menu > LVD > LVD
July 2007
