Installation; Overview - Eaton Powerware 3G System SC200 Installation And Operation Manual

4
C h a p t e r 3

Installation

Overview

Topic
Installation Tasks
Task 1 - Check the AC Supply and Earthing
Task 2 - Fixing the Power System Cabinet(s)
Task 3 - Connect the DC Output to Earth
Task 4 - Connect the DC Load Cables
Task 5 - Connect Battery Cables (if required)
Task 6 - Install the Batteries
Task 7 - Mount the Battery Temperature Sensor
Task 8 - Connect External Current Sensors/Shunts (if required)
Task 9 - Connect Input/Output Cabling (if required)
Task 10 - Connect Additional Input/Output (if required)
Task 11 - Connect to the AC Supply
Installation Completed
Copyright © 2005-2007 Eaton Corporation. All Rights Reserved.
IPN 997-00012-54A
Installation
July 2007
Chapter 3
Page
14
15
18
20
22
23
25
28
29
29
30
31
35
