3G-SC200 Data-Voice-Video Power Solutions Installation Guide
Rectifiers
Operating Ranges
AC Input Current (maximum)
Rated Output Power
Rated Output Current
Preset Voltage
Rectifier AC Fuses (internal)
Environment
Ambient Temperature Range (operating)
Relative Humidity (operating and storage)
Dimensions H, W, D
Cabinets
Rectifiers
Weight
Excluding rectifiers and batteries
Rectifier
60
Rated:
Extended:
Copyright © 2005-2007 Eaton Corporation. All Rights Reserved.
IPN 997-00012-54A
175 – 275V
Full output up to 50°C [122°F]
90 – 300V
Reduced output power below 175V
APR24-3G: 9.5A
APR48-3G: 12A
175V AC, 20°C [68°F]
APR24-3G: 1440W
APR48-3G: 1800W
APR24-3G: 50A @ 28.8V
APR48-3G: 37.5A @ 48V
31.25A @ 57.6V
APR24-3G: 27V ± 0.1
APR48-3G: 54.5V ± 0.1V
16A, 250V
-5°C to 50°C [ 23°F to 122°F]
<95% (non condensing)
43U racks: 2000mm [78.7"], 600mm [23.6"],
600mm [23.6"]
3U: 133mm [5.25"], 42mm [1.65"], 266mm
[10.45"] overall
Systems with integrated batteries:
85kg [188 lb] typical
Systems without integrated batteries:
120kg [264 lb] typical
Additional battery rack option:
85kg [188 lb] typical
1.7kg [3.7 lb]
