Equipment Required:
DC Load bank
•
Test Test procedure
•
Voltage Control
•
Note 1
•
Temperature
•
Compensation
Note 2
•
Equalize
•
•
•
•
•
•
Fast Charge
•
Note 3
•
•
•
•
•
•
•
•
•
80
Apply a load to the power system.
With DCTools, ensure the bus voltage matches
the Target Voltage as shown on the Voltage
Control Summary of DCTools.
Heat the battery temperature sensor.
Ensure the system voltage changes in accordance
with the configured slope.
Set the Equalize Duration to 1 minute.
Start an Equalize.
Ensure the system voltage increases to the
Equalize Voltage.
Ensure the SC200 indicates an Equalize has
started.
Ensure the Equalize stops after the 1 minute
duration.
Return the Equalize duration to the original
setting.
Set the Fast Charge Max Duration to 1 minute.
Set the Fast Charge Voltage Threshold to a value
approximately 1V below the system float
voltage.
Connect load to the system.
Turn off the AC to the system.
Allow the system voltage to fall below the Fast
Charge Voltage Threshold.
Turn on the AC.
Ensure the system performs a Fast Charge.
Ensure the SC200 indicates a Fast Charge has
started.
Ensure the Fast Charge Voltage is correct.
Ensure the Fast Charge stops after 1 minute.
Return the Fast Charge settings to the original
values.
