Step 1 - Route and connect cable to DV2-3G
1
2
3
4
Step 2 - Connect the cable to socket YH11 on the SiteSure-3G module
Procedure complete
For details on setup refer to the SiteSure-3G Installation Guide. Refer to Related Information
on page i.

Task 11 - Connect to the AC Supply

Step 1 - Access AC MCBs (systems with integrated battery shelves)
Route an RJ45 patch cable from the SiteSure-3G module to the DV2-3G.
Connect the cable to an RJ45 socket (S1, S2 or S3) on the Voltage Feed Module
board via an RJ45 splitter. See diagram on page 7 for socket location.
Use cable ties to secure the cable and prevent strain on the connectors.
Test the insulation and continuity of the conductors.
•
If the DC power system is to be installed in a location where the ambient
temperature may rise above 50ºC (122ºF), then V110 rated cable must be used for
all connections.
•
Only use a three-phase (Δ) AC power source that is referenced to earth, or has a
protection system in place to prevent the phase-earth voltage exceeding the rating
of the rectifier.
Ignore this step if system does not have integrated battery shelves.
The AC MCBs are fitted in the combined AC and DC distribution
1
section. Refer to the diagram on page 2 for location. The layout of the
AC MCBs is shown in the following diagram.
To access the MCBs:
2
•
Open AC/DC distribution space door.
•
Switch the AC isolator to the OFF position.
•
Undo the four screws securing the perspex cover and remove the
cover.
Go to Step 3.
3
