Indicator Lamps

Display

EasyCoder PM4i Printer User's Guide (Fingerprint Version)
The indicators are colored LEDs (Light Emitting Diodes) and are
used for the following purposes:
LED
Power
Status
Status
Status
Intermec Ready-to-
Work Indicator
The Intermec Ready-to-Work Indicator
determine the readiness of the Intermec device individually and
as part of a solution. The Intermec Ready-to-Work Indicator has
three different states: On, Blinking, and Off. When the Indicator
is off, the device is not ready to operate individually or as part of
a solution. When the Indicator is blinking, the device may be
initializing, waiting for external resources, or in need of user
attention. And when the Indicator is On, the device is ready for
use as part of a solution. Also see Chapter 9.
The display window contains an LCD (Liquid Crystal Display)
with background illumination and two lines of text, each with 16
characters. It provides information on installed firmware or
running application, prompts the operator in Intermec Shell and
in the Setup Mode, and can show information on possible errors
and active communication channels.The Intermec Fingerprint
programming language and the Intermec Direct Protocol allow
custom-made messages to be composed and displayed according
to the requirements of the application.
Chapter 2 — Installation
State
Solid green
Solid green
Flashing green
Solid red
On, blinking, or off
helps users quickly
™
Description
Indicates that the
power is on.
Indicates that the
printer is ready for use.
Indicates that the
printer is
communicating.
Indicates an error
condition
(see"Troubleshooting"
on page 89).
Determines the
readiness of the
Intermec device.
13
