Chapter 6 — Setting Up the Printer
58
• A negative start adjustment means that the specified length of
media will be pulled back before the printing starts. Thus, the
origin is moved towards the forward edge of the copy.

Stop Adjust

The Stop Adjust value is given as a positive or negative number of
dots. Default value is 0, which stops the media feed in a position
suitable for tear off operation.
• A positive stop adjustment means that the normal media feed
after the printing is completed will be increased by the
specified value.
• A negative stop adjustment means that the normal media feed
after the printing is completed will be decreased by the
specified value.

Recommended Feed Adjustments

The following settings allow printing from the top of the label.
Minor deviations from the recommended values may be required
due to various combinations of media types, roll size, type of
media supply device, and individual differences between printers.
8 dots/mm
Adjustment 203.2 dpi
Type (std)
Tear-Off (Straight-through)
Start adjust: -100 dots
Stop adjust: 0 dots
Peel-Off (Self-strip)
Start adjust: -56 dots
Stop adjust: -44 dots
Cut between labels w. gaps
Start adjust: -325 dots
Stop adjust: +240 dots
Cut fix and variable length strip
Start adjust: -340 dots
Stop adjust: +340 dots
EasyCoder PM4i Printer User's Guide (Fingerprint Version)
11.81 dots/
mm 300 dpi Distance
(option) in mm
-148 dots 12.5
0 dots 0
-83 dots 7
-65 dots 5.5
-480 dots 40.6
+354 dots 30.0
-502 dots 42.5
+502 dots 42.5
Distance
in inches
0.49
0
0.28
0.22
1.6
1.18
1.67
1.67
