Intermec Direct Protocol

Default Setup

EasyCoder PM4i Printer User's Guide (Fingerprint Version)
• Use setup strings to change individual setup parameters
remotely from the host.
See the Intermec Fingerprint Command Reference Manual
(P/N 937-005-XXX).
The printer's default setup is listed below (assuming no options
installed):
Ser-Com "uart1:"
Baud rate
Character length
Parity
Stop bits
RTS/CTS
ENQ/ACK
XON/XOFF; data to host
XON/XOFF; data from host
New line
Receive buffer
Transmit buffer
Feedadjust
Startadjust
Stopadjust
Media:
X-start (8 dots/mm = 203.2 dpi)
X-start (11.81 dots/mm = 300 dpi)
Width (8 dots/mm = 203.2 dpi)
Width (11.81 dots/mm = 300 dpi)
Length (8 dots/mm = 203.2 dpi)
Length (11.81 dots/mm = 300 dpi)
Chapter 6 — Setting Up the Printer
9600
8 bits
None
1 bit
Disable
Disable
Disable
Disable
CR/LF
1024 bytes
1024 bytes
0 dots
0 dots
24 dots
36 dots
832 dots
1248 dots
1200 dots
1800 dots
