Intermec Ready-To-Work Indicator - Intermec EasyCoder PM4i User Manual

Chapter 10 — Troubleshooting

Intermec Ready-to-Work Indicator

Display Messages and LED Indications
90
The readiness of the printer, individually or as a part of a
solution, is indicated by the blue Intermec Ready-to-Work
Indicator (IRI).
If the IRI blinks or is switched off, the printer is not ready.
Further information can be obtained in the display window by
pressing the F5/i key. In case of several errors or similar
conditions occurring simultaneously, only the most significant
error is displayed. Once this error has been cleared, next
remaining error is displayed.
The printer will also return error messages to the host, provided
there is a working two-way communication. Refer to the Intermec
Fingerprint Developer's Guide (P/N 934-019-XXX).
Provided the printer is connected to a network, all conditions
that prevents printing are reported to the Easy ADC Console.
The Easy ADC Console is a PC-based software which allows a
supervisor to monitor all connected devices that have an
Intermec Ready-to-Work, including handheld computers, access
points, and printers.
Error/Event RtW
Operational On
Out of paper Blink
Next label not Blink
found
Label not taken Blink
Out of transfer Blink
ribbon
Transfer ribbon is Blink
installed
Head lifted Blink
Cutter does not Blink
respond
Cutter error1 Blink
Cutter error2 Blink
EasyCoder PM4i Printer User's Guide (Fingerprint Version)
Error
No. Comment
0 No error
1005
1031
1027
1058
1022
1059
1701
1702
