Tickets With Gaps

EasyCoder PM4i Printer User's Guide (Fingerprint Version)
a
c
d
b
⇐ a ⇒ Media Width
Maximum:
Minimum:
⇐ b ⇒ Copy Length
Max. length between slots: depends on SDRAM size
Min. length between slots: 8.0 mm (0.32 in)
Under ideal circumstances, a minimum ticket length of 4 mm
(0.16 in) could be used. It requires the sum of the copy length (b)
and the detection slit height (e) to be larger than 7 mm (0.28 in),
that batch printing is used, and that no pull back of the media is
performed. Intermec does not guarantee that such short tickets
will work, but it is up to the user to test this in his unique
application.
Appendix B — Media Specifications
e
b
114.3 mm (4.50 in)
25.0 mm (1.00 in)
135
