Names of Parts and Their Functions

Front Side
Check these parts on the front when operating the machine.
Front Side(P. 9)
● Use the control panel to operate the machine and configure the settings.
Control Panel(P. 13)
● Place the original on the platen glass or in the feeder when scanning, sending a fax, or copying.
2-Sided Double Pass Feeder(P. 18)
1-Sided Feeder(P. 19)
● Load printing and copying paper into the following paper sources:
Multi-purpose Tray(P. 20)
Drawer(P. 21)
Back Side
Check the rear parts when installing and connecting the machine and when clearing paper jams.
Back Side(P. 11)
Interior
Open the covers and access the interior to replace a toner cartridge or to remove jammed paper.
Interior(P. 12)
