Canon imageCLASS MF266dn II User Manual page 77

When selecting the SSID of the wireless LAN router supporting WPA-EAP or WPA2-EAP for the security
standard, the message [IEEE 802.1X Settings values will be applied to connect.] appears. Press [OK], and
proceed to Step 4.
If you cannot find the wireless LAN router to which you want to connect, check that the router is
discoverable. Cannot Connect to Wireless LAN(P. 591)
3
Enter the network key, and press [Apply].
4
Check the message, and press [Yes].
5
When [Connected.] is displayed on the control panel, wait a few minutes.
➠
When the machine is connected to the wireless LAN, [
each function.
By default, an IP address is set automatically.
To use a specific IP address, set this manually.
Setting IPv4 Addresses(P. 75)
Setting IPv6 Addresses(P. 79)
If an Error Message Appears during Operation and a Connection Cannot Be Established
● Press [Close], check the information (SSID or network key) of the wireless LAN router to which you want to
connect, and repeat the procedure starting from Step 2.
5 Lines LCD Model
Required Preparations
● Prepare the information of the wireless LAN router (SSID or network key) to which you want to connect, and
keep it close by. Wireless LAN Router Information Required for Connection(P. 60)
● When connecting to a wireless LAN router supporting WPA-EAP or WPA2-EAP for the security standard, set
IEEE 802.1X. Using IEEE 802.1X(P. 361)
1
On the control panel, select [Wireless LAN Set.] in the [Home] screen and press
[Home] Screen(P. 118)
➠
The [Select Network] screen is displayed.
● If the login screen appears, enter the System Manager ID and PIN, and then select [<Log In>] and press
. Logging In to the Machine(P. 135)
● If the message [Enable the wireless LAN?] appears, select [Yes] and press
● If the message [Cannot find the access point.] appears, check that the router is discoverable.
Connect to Wireless LAN(P. 591)
Setting Up
] appears on the [Home] screen and screen of
68
.
