Rear Panel - Teldat M20 Installation Manual

3 Components and Power Supply
Ethernet RJ45 interface LEDs
Fig. 4:
The table below provides information on the LEDs associated with the RJ45 Ethernet interfaces:
RJ45 Ethernet interface LED indicators
LED
Left (Link)
Right (Speed)
None
Combo SFP interface LEDs
Fig. 5:
The table below provides information on the LEDs associated with the Combo SFP interfaces:
Combo SFP and SFP+ LED indicators
LED
Green

3.1.2 Rear panel

The following figure shows the rear panel.
Rear panel
Fig. 6:
The following table provides information and a description of each component:
Rear panel components
Item
A
B
6
Description
- Yellow: Link/Activity indicator
- Yellow: Linked at 1000Mbps
- Green: Linked at <1000Mbps
Interface is unavailable, not installed, or not registered.
Description
Ethernet link connection
Description
Bonding screw for protective earth.
Refer to Ground the router
Power socket.
Refer to Power source
State
Off: Link has not been detected.
On: Link detected.
Blinking: connection data activity.
on page 9 for more information.
on page 9 for more information on Power Connection and
Windbit
M20 Edge Router
