3.1.1.1 LEDs
The LED panel provides information on the status of the components (whether they are active or not) and on the net-
work activity.
Front panel LEDs
Fig. 3:
LEDs
LED
A
B
In addition to the LEDs described in the above table, the front panel also has LEDs linked to the Combos RJ45 and
RJ45 Ethernet interfaces.
M20 Edge Router
2x Gigabit Ethernet Combo (RJ45/SFP) ports.
For more information on the Gigabit Ehternet combo interfaces, refer to:
- Ethernet Combo connections (ETH1 to ETH2)
- Ethernet RJ45 connector
- Ethernet SFP connector
- Ethernet interface, RJ45 Port
- Ethernet interface, SFP Port
8x Gigabit Ethernet Switch ports (10/100/1000 RJ45) ports.
For more information on the Gigabit Ehternet SFP+ interfaces, refer to:
- 8-port Ethernet switch connections (ETH0)
- Ethernet RJ45 connector
- Ethernet interface, RJ45 Port
Definition
Power Status
System
on page 19
on page 20
on page 21
on page 21
on page 11
on page 19
on page 21
Status Indication
Off: Error.
On: Power Input OK.
Off: System error.
On: System initialized and operating.
