Technical Information
A.4.2 Ethernet SFP connector
SFP
A.4.3 USB 3.0 connector
Type-A
A.4.4 Configuration connector
RJ45 CONFIGURATION
A.5 Technical specifications
20
Standard SFP connector
PIN
1
2
3
4
5
6
7
8
Shell
RJ45 PIN
1
2
3
4
5
6
7
8
Signal
VBUS
D- (USB 2.0)
D+ (USB 2.0)
SSRX- (USB 3.0)
SSRX+ (USB3.0)
GND_DRAIN
SSTX- (USB 3.0)
SSTX+ (USB 3.0)
Shield
CONF
--
--
TxD
GND
GND
RxD
--
--
Windbit
M20 Edge Router
