A.5.1 Hardware architecture
PROCESSORS
MEMORY
STORAGE UNIT
A.5.2 Ethernet interface, RJ45 Port
PROTOCOLS
SPEED
PORTS
CONNECTOR
A.5.3 Ethernet interface, SFP Port
STANDARDS
SPEED
TYPES
PORTS
CONNECTOR
A.5.4 USB interface
TERMINAL
CONNECTOR
A.5.5 Configuration interface
LOCAL TERMINAL
CONNECTOR
M20 Edge Router
Freescale LayerScape 4-core architecture.
4 GByte (DDR4).
eMMC Memory (16 GBytes).
IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3x Full-Duplex Flow Control.
10/100/1000 Mbps (Base-T) with MDI/MDX autodetection
8-port switch managed (ETH0)
2-port (Combo, metallic port) (ETH1, ETH2)
RJ45 female.
1000Base-X.
MSA and SFF 8472 compliant.
1000 Mbps full duplex.
LX/LH (single-mode 1310 nm).
SX (multi-mode 850 nm).
ZX (single-mode 1550 nm).
2-port (Combo, SFP port) (ETH1, ETH2)
Standard SFP connector.
One USB 3.0 (Super Speed).
Type-A.
RS-232 115200-8-N-1 without flow control.
RJ45 female on the device's front panel.
