SOUND BUSTER
Appendix D
Connecting
Internal PC
Speaker
I is possible o connec he in ernal PC speaker o he Sound Blas er Pro.
However, due o he varia ions of in ernal PC speaker connec ions found
on differen sys ems, you may need an experienced PC echnician o
comple e his procedure or you may wan o seek he help of your local
compu er dealer.
rocedures For
C Technicians
Orally
To connec in ernal PC speaker:
1. Loca e he PC speaker connec ion on he mo herboard.
2. Remove he connec ion o he in ernal PC speaker.
3. From he mo herboard, connec a wire from he +5 Vdc pin of he
speaker connec or o pin 1 of JP1 on he Sound Blas er Pro.
5. Connec ano her wire from he Da a ou pin of he mo herboard
speaker connec or o pin 2 of JP1 on he Sound Blas er Pro.
6. You will need o provide yourown sui able connec ing wires and
socke s.
Caution
DO OT ATTEMPT TO FIX THE CO ECTIO YOURSELF IF
YOU ARE OT SURE OR ELSE YOU MIGHT DAMAGE YOUR PC
OR THE SOU D BLASTER PRO. CREATIVE LABS, I C. OR
THEIR DISTRIBUTORS WILL OT BE LIABLE FOR SUCH
DAMAGES.
Appendixes £s
-15
