- Page 2 Creative Modem Blaster V.92 PCMCIA DI5611 Information in this document is subject to change without notice and does not represent a commitment on the part of Creative Technology Ltd. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose without the written permission of Creative Technology Ltd.
- Page 3 Contents...
-
Page 4: Table Of Contents
Contents Before You Begin Package Contents ... v Recording Model and Serial Numbers... v Checking System Requirements... v Technical Support and Warranty ... vi Product Registration... vi Document Conventions... vii 1 Installing and Testing the Driver Installing the Driver In Windows XP/2000/Me/98 SE... 1-1 Testing the Driver... - Page 5 In Windows 98 SE/Me... 3-2 4 Modem Features Plug and Play... 4-1 Faxes ... 4-1 Internet Access... 4-1 Videoconferencing... 4-1 V.92 features ... 4-2 V.44 Data Compression... 4-2 Quick Connect... 4-2 PCM Upstream... 4-2 Modem-On-Hold... 4-3 Using Incoming Modem-On-Hold... 4-4 Using Outgoing Modem-On-Hold ...
- Page 6 Resolving Conflicts in Windows Me/98 SE... B-3 Difficulties with Your PC Card ... B-3 Difficulties with Modem-On-Hold ... B-5 Difficulties In Windows XP ... B-7...
- Page 7 Before You Begin...
-
Page 8: Before You Begin
Before You Begin This section contains information you should know about before using this manual. Read the information carefully before proceeding further. • Creative Modem Blaster Package Contents • Telephone adapter cord (RJ-11) • Telephone cord coupler (RJ-11) • Quick Start Leaflet •... -
Page 9: Technical Support And Warranty
<language> with the language that the document is in) Enjoy a host of benefits by registering your products during installation, or at Product www.creative.com/register. Benefits include: Registration • Service and Product Support from Creative • Exclusive updates on promotions and events Before You Begin vi... -
Page 10: Document Conventions
The following typographical conventions are used throughout this document. Document Conventions Note. This highlights additional or important information about a feature. Caution! This highlights proper usage of your product. Use this information to avoid risky situations. Warning! This warns you of possible hazards to yourself or your product, that may result in injury or damage. -
Page 11: Installing And Testing The Driver
Installing and Testing the Driver... -
Page 12: Installing The Driver In Windows Xp/2000/Me/98 Se
Installing and Testing the Driver DO NOT insert the PC Card into your notebook computer before installing the Installing the software. Driver In Insert the Installation CD into your CD-ROM drive. The disc supports Windows Windows XP/ AutoPlay mode and starts running automatically. If not, enable your CD-ROM 2000/Me/98 SE drive’s auto-insert notification feature. -
Page 13: Testing The Driver
In Windows XP Double-click the Phone and Modem Options icon. Click the Modems tab. Click Creative Modem Blaster V.92 PCMCIA DI5611, and then click the Properties button. The Creative Modem Blaster V.92 PCMCIA DI5611 Properties dialog box appears. Click the Diagnostics tab, and then click the Query Modem button to display the response status of your PC Card (Figure 1-1). -
Page 14: In Windows 2000
In Windows 2000 Double-click the Phone and Modem Options icon. Click the Modems tab. Click Creative Modem Blaster V.92 PCMCIA DI5611, and then click the Properties button. Click the Diagnostics tab. The Creative Modem Blaster V.92 PCMCIA DI5611 Properties dialog box appears. -
Page 15: In Windows 98 Se/Me
Click Start -> Settings -> Control Panel. In Windows 98 SE/ Double-click the Modems icon. The Modems Properties dialog box appears. Click the Diagnostics tab (Figure 1-3). Click the COM port that has been assigned to your modem. Click the More Info button to display the response status of your PC Card. -
Page 16: Installing Hardware
Installing Hardware... -
Page 17: Installation Steps
Installing Hardware DO NOT insert the PC Card into your notebook computer before installing the Installation software. Steps Insert your PC Card into an available PC Card slot on your notebook Step 1: Prepare (Figure 2-1). your computer For Windows XP only When the Found New Hardware Wizard dialog box appears, click the Next button. -
Page 18: Step 2: Connect To The Telephone Line
Locate the most convenient telephone wall outlet. Step 2: Connect to If a telephone is already connected to it, unplug the telephone cable from the the telephone line wall outlet. Connect one end of the telephone adapter cord provided to the wall outlet and the other end to the PC Card 4-pin port of the PC Card (Figure 2-2). -
Page 19: Notes On Connecting The Telephone Line And Telephone
If your notebook is too far away from the wall outlet, use the telephone cord coupler to extend the telephone adapter cord. See Figure 2-3 below. Before using the PC Card, you need to connect your telephone line and telephone Notes on to the PC Card. -
Page 20: Uninstalling The Driver
Uninstalling the Driver... -
Page 21: Uninstalling Pc Card
For Windows XP, click Start -> Control Panel. Double-click the Add or Remove Programs icon. Click the Change or Remove Programs button (Figure 3-1). Click Creative Modem Blaster V.92 PCMCIA DI5611, and then click the Change/Remove button. Turn off your computer and remove the PC Card. -
Page 22: In Windows 98 Se/Me
Double-click the Add/Remove Programs icon. The Add/Remove Programs Properties dialog box appears. Click the Install/Uninstall tab (Figure 3-2). Click Creative Modem Blaster V.92 PCMCIA DI5611, and then click the Add/Remove button. Turn off your computer and remove the PC Card. -
Page 23: Modem Features
Modem Features... -
Page 24: Plug And Play
Modem Features Besides transferring data and accessing online information, your Creative Modem Blaster has the following features: This feature allows you to install your PC Card easily, as it is automatically Plug and Play configured. Use your PC Card to send and receive fax documents. This feature also allows you... -
Page 25: V.92 Features
V.92 features Your Internet Service Provider (ISP) must be able to support the following V.92 features before you can use them. V.44 Data Compression reduces the time it takes to load web pages, run web V.44 Data searches, and receive e-mail with new compression designed specifically for the Compression Internet. -
Page 26: Modem-On-Hold
Your Modem Blaster offers complete Modem-On-Hold support so you can pause Modem-On- your Internet connection while you answer incoming phone calls and while you Hold make outgoing phone calls. Since Modem-On-Hold also requires support from your ISP, you may need to check with them to ensure that this feature is supported in your area. -
Page 27: Using Incoming Modem-On-Hold
If a call comes in while you are on the Using Incoming Internet, a dialog box similar to Figure Modem-On-Hold 4-1 appears, asking you if you want to answer the call, click the Accept button • Your phone line needs to be Call A dialog box similar to Figure 4-2 Waiting enabled to appears, telling you the length of time... -
Page 28: Using Outgoing Modem-On-Hold
Using Outgoing Modem-On-Hold Click the NetWaiting icon taskbar. A dialog box similar to Figure 4-3 appears. Click the Outgoing call button • Modem-On-Hold requires Three-Way You can start making your phone call. Calling to make A dialog box similar to Figure 4-4 phone calls. -
Page 29: A Technical Specifications
Technical Specifications... -
Page 30: Plug And Play
Technical Specifications This appendix lists the general specifications of your modem. ❑ Plug and Play resources. Plug and Play Figure A-1: Plug and Play Resource Information. EPENDENT FUNCTIONS Choice 1 COM 3 Choice 2 COM 4 Choice 3 COM 2 Choice 4 COM 1 Choice 5... -
Page 31: Data Features
❑ Data Features Integrated data, fax, and voice mail modem. ❑ 56,000/54,667/53,333/52,000/50,667/49,333/48,000/46,667/45,333/42,667/41,333/ 40,000/38,667/37,333/36,000/34,667/33,333/32,000 ❑ 33,600/31,200/28,800/26,400/24,000/21,600/19,200/16,800/14,400/ 12,000/9,600/ 7,200/4,800/2,400/1,200/300 bps data speeds. Due to line ❑ conditions and FCC Compatibility with the following data modem standards: regulations, your • V.92, V.90, V.34, V.32bis, V.32, V.23, V.22bis, V.22, and V.21; Bell 212A and 103. -
Page 32: Troubleshooting
Troubleshooting... -
Page 33: Difficulties Installing Software
Troubleshooting This appendix provides tips and solutions for resolving some of the difficulties you might encounter with Creative Modem Blaster V.92 PCMCIA DI5611, either during installation or normal use. The installation does not start automatically after the Creative Modem Difficulties Blaster Installation CD is inserted. -
Page 34: Resolving Hardware Conflicts
In the Properties dialog box, click the Settings tab and select Auto Insert Notification. Click the OK button to exit from the dialog box. Resolving Hardware conflicts may occur when two or more peripheral devices are set to use the same I/O address, IRQ line or DMA channel. Hardware To resolve conflicts in Windows XP, Windows 2000, Windows Me or Windows 98 SE, Conflicts... -
Page 35: Difficulties With Your Pc Card
To run Device Manager: Resolving Conflicts Click Start -> Settings -> Control Panel. in Windows Me/98 Click the System icon. The System Properties dialog box appears. Click the Device Manager tab. Double-click Modem. Select your PC Card and click the Properties button. The Properties dialog If you are unsure of box of the PC Card appears. - Page 36 Try moving the telephone line away from any power source, monitor, printer or any computer cable. The PC Card cannot connect to the Internet at 56,000 bps. This may be due to line conditions in your area. Due to FCC regulations and/or line conditions, it is not always possible to achieve the maximum data rate.
-
Page 37: Difficulties With Modem-On-Hold
No dial tone when using the PC Card. The IRQ of the PC Card is either in conflict with another device or is mis-reported in Windows. To resolve this difficulty: Many chipsets have IRQ routing drivers for Windows. If you have an internal PC Card, and these drivers do not work or do not exist on your system, insert the PC Card into a different PC Card slot. - Page 38 Click the Dial Properties button, and then click the check box next to the To disable call waiting, dial option. Click the arrow next to the To disable call waiting, dial box. Three options are displayed: *70, 70# and 1170. Select the appropriate option.
-
Page 39: Difficulties In Windows Xp
You may see this message when installing this driver or update. If you do, you may choose to click the Continue Anyway button. Creative has tested this driver on Windows XP, and it does not impair or destablize your computer.
