Model CT5801 OEM Guide
Creative Sound Blaster AudioPCI 128
PCI Audio Card Hardware Applications
Revision 1.0, October 25, 2000
Note: This information is Confidential and Proprietary to Creative Labs, Inc. This information is subject to change without prior
notice. Released by OEM Technical Marketing Department. Please direct any inquiries to your regional OEM Sales office. Patent
Pending.
Revision 1.0, 10/25/2000
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pavilion xl700 - Desktop PC and is the answer not in the manual?

Questions and answers

Summary of Contents for Creative Pavilion xl700 - Desktop PC

  • Page 1 Model CT5801 OEM Guide Creative Sound Blaster AudioPCI 128 PCI Audio Card Hardware Applications Revision 1.0, October 25, 2000 Note: This information is Confidential and Proprietary to Creative Labs, Inc. This information is subject to change without prior notice. Released by OEM Technical Marketing Department. Please direct any inquiries to your regional OEM Sales office. Patent Pending.
  • Page 2: Revision History

    Revision History Revision Written/Changes Dated Revision History Made By Joanne Scanlon 10-25-00 Updated card picture to include PC99 colors on bracket. Note: This information is Confidential and Proprietary to Creative Labs, Inc. This information is subject to change without prior notice.
  • Page 3: Table Of Contents

    Table of Contents REVISION HISTORY ..........................2 INTRODUCTION ............................4 SB AUDIOPCI 128 CONFIGURATIONS ....................5 SYSTEM REQUIREMENTS ........................5 SB AUDIOPCI 128 SERIES FEATURES....................5 ............................5 IGITIZED OUNDS ............................6 YNTHESIZED USIC .........................6 OMMUNICATIONS NTERFACE Telephone Answering Device (TAD) interface ....................6 ....................6 REATIVE TEREO IGITAL NALOG IXER...
  • Page 4: Introduction

    Introduction This document is intended to provide a complete technical description of the features and specifications of the Sound Blaster AudioPCI 128 advanced PCI audio cards. The SB AudioPCI 128 is a PCI audio chipset solution from the Ensoniq division of Creative Technology Ltd.
  • Page 5: Sb Audiopci 128 Configurations

    SB AudioPCI 128 Configurations SB AudioPCI 128 Series is fully configurable as a professional quality audio. The features shown in the table below are described in detail in the following section of this document. SB AudioPCI 128 Series is available in the following configuration: Model Config Host 2,4,8 MB 3D Sound,...
  • Page 6: Synthesized Music

    CCITT A-law (16:8) ii. CCITT -law (16:8) Up to 128 simultaneous voice polyphony Full DOS Game Compatibility 3 Stereo inputs and 2 mono inputs can be mixed into the output stream. Direct I/O space access of the control registers. 100 Pin PQFP or TQFP External SPDIF Connector Fully Compliant with PC99 Power Management specification Synthesised Music...
  • Page 7: Sampling Subsystem

    2MB, 4MB, & 8MB sample sets Sampling Subsystem Host memory support Virtually unlimited variations of sound 3D Audio Technology Supports EAX 1.0 Multi-algorithm Reverb and Chorus Support Microsoft DirectSound 3D Support Aureal A3D API Improves sound clarity, spatial realism and sound effects, through the minimization of crosstalk Dynamically adjust for monophonic or stereophonic input without user intervention Joystick Port Standard PC joystick port for 1 or 2 joysticks.
  • Page 8: Es1373 Integrated Audio Chip - General Description

    ES1373 Integrated Audio Chip - General Description The ES1373 solution is Sound Blaster 16 compatible via emulation, Roland MPU401 compatible via emulation and in full compliance with Multimedia PC Level 3 specifications. In addition, the ES1373 meets Plug and Play specifications, eliminating any requirement for the user to select I/O and DMA address settings through hardware or software.
  • Page 9: Power Management

    Power Management All power management of the system is under software control. The AC97 CODEC and ES1373 can be powered down separately. Neither chip loses register information when powered down. The ES1373 can be power managed by shutting down various sub-systems. The following blocks can be individually powered down: Joystick, UART, and Serial Interface.
  • Page 10: Es1373 Integrated Audio Chip - Block Diagram

    ES1373 Integrated Audio Chip - Block Diagram Note: This information is Confidential and Proprietary to Creative Labs, Inc. This information is subject to change without prior notice. Released by OEM Technical Marketing Department. Please direct any inquiries to your regional OEM Sales office. Patent Pending.
  • Page 11: Sb Audiopci 128 - Es1373 Series Connections And Jumpers

    SB AudioPCI 128 – ES1373 Series Connections and Jumpers The board consists of the following connectors that support the connection of internal devices or hardware configuration changes: CD Audio In – J6 4 pin Molex CD Audio connector TV Tuner – J8 4 pin Molex connector Connector for TV Tuner, IDE CD Audio or other auxiliary audio input TAD I/O –...
  • Page 12: Adapter Cable For S/Pdif Feature

    Adapter Cable for S/PDIF Feature Length: 6 Feet Impedance: 75 Ohm Type: Coaxial Soundcard End: 3.5 mm Male (Earphone) Mono Plug Receiver End: RCA (Male) Plug The cable shield is connected to the sleeve of the 3.5 mm plug and the sleeve of the RCA plug. The center conductor is connected to the tip of both the RCA plug and the 3.5 mm plug.
  • Page 13: Internal Connectors - Pin Assignments

    Internal Connectors - Pin Assignments CD Audio Connectors J6 - Molex CD-IN Pin Assignments SIGNAL Left Channel Ground Ground Right Channel J8 - Molex TV Tuner Pin Assignments SIGNAL Left Channel Ground Ground Right Channel J10 - Molex TAD Pin Assignments SIGNAL Modem Audio In Ground...
  • Page 14: Sb Audiopci 128 - Es1373 Series Specifications

    SB AudioPCI 128 – ES1373 Series Specifications Typical Audio Performance Frequency Response 20 Hz to 20 kHz (Source: Line in) (+0/-3dB) 20 Hz to 20 kHz (Source: Mic) Line-In Voltage Range 0 to 2 Vrms Line-Out voltage at 0dB 0 to 2 Vrms (10kohms load) Reference signal 1KHz (measured with wide-band filter 22Hz-22kHz): Signal to Noise Ratio >...
  • Page 15 Creative Offices International inquiries: Americas Inquiries: Creative Technology Ltd. Creative Labs, Inc. 31 International Business Park 901 McCarthy Boulevard Creative Resource Milpitas, CA 95035 Singapore 609921 Tel: +1 (408) 428 6600 Tel: +65 895 4000 Fax: +1 (408) 428 2394 Fax: +65 895 4050 Creative Media K.K.
