STC8A8K64D4 Series Manual
DMA_M2M_AMT FA03H
DMA_M2M_AMT: Set
Note: The actual number of bytes read and written is (DMA_M2M_AMT+1), that is, when
DMA_M2M_AMT is set to 0, 1 byte is read and written, and when DMA_M2M_AMT is set to 255, 256
bytes are read and written.

23.2.5 M2M_DMA transfer complete byte register (DMA_M2M_DONE)

Symbol Address
DMA_M2M_DONE FA04H
DMA_M2M_DONE: The number of bytes that have been read and written currently.

23.2.6 M2M_DMA Send Address Registers (DMA_M2M_TXAx)

Symbol Address
DMA_M2M_TXAH FA05H
DMA_M2M_TXAL FA06H
DMA_M2M_TXA: Set the source address when reading and writing data. Data will be read from this address when
the M2M_DMA operation is performed.

23.2.7 M2M_DMA Receive Address Registers (DMA_M2M_RXAx)

Symbol Address
DMA_M2M_RXAH FA07H
DMA_M2M_RXAL FA08H
DMA_M2M_RXA: Set the target address when reading and writing data. Data will be written from this address when
the M2M_DMA operation is performed.
the number of bytes
B7 B6 B5
B7 B6 B5
B7 B6
that need to
B4 B3
B4 B3
ADDR[15:8]
ADDR[7:0]
B5 B4 B3
ADDR[15:8]
ADDR[7:0]
read and write data.
B2 B1 B0
B2 B1 B0
B2 B1 B0
- 638 -
