STC8A8K64D4 Series Manual

3.1.5 Enhanced PWM Control Register (PWMnCR)

Symbol Address
PWM0CR FF14H
PWM1CR FF1CH
PWM2CR FF24H
PWM3CR FF2CH
PWM4CR FF34H
PWM5CR FF3CH
PWM6CR FF44H
PWM7CR FF4CH
C0_S[1:0]: Enhanced PWM Channel 0 Output Pin Select Bits
C0_S[1:0] PWM0
00 P2.0
01 P1.0
10 P6.0
11 Reserved
C1_S[1:0]: Enhanced PWM Channel 1 Output Pin Select Bits
C1_S[1:0] PWM1
00 P2.1
01 P1.1
10 P6.1
11 Reserved
C2_S[1:0]: Enhanced PWM Channel 2 Output Pin Select Bits
C2_S[1:0] PWM2
00 P2.2
01 P1.2
10 P6.2
11 Reserved
C3_S[1:0]: Enhanced PWM Channel 3 Output Pin Select Bits
C3_S[1:0] PWM3
00 P2.3
01 P1.3
10 P6.3
11 Reserved
C4_S[1:0]: Enhanced PWM Channel 4 Output Pin Select Bit
C4_S[1:0] PWM4
00 P2.4
01 P1.4
10 P6.4
11 Reserved
C5_S[1:0]: Enhanced PWM Channel 0 Output Pin Select Bit
C5_S[1:0] PWM5
00 P2.5
01 P1.5
10 P6.5
11 Reserved
C6_S[1:0]: Enhanced PWM Channel 0 Output Pin Select Bit
C6_S[1:0] PWM6
00 P2.6
01 P1.6
10 P6.6
11 Reserved
C7_S[1:0] : Enhanced PWM Channel 7 Output Pin Select Bit
C7_S[1:0] PWM7
00 P2.7
01 P1.7
10 P6.7
11 Reserved
B7 B6 B5
ENC0O C0INI
ENC1O C1INI
ENC2O C2INI
ENC3O C3INI
ENC4O C4INI
ENC5O C5INI
ENC6O C6INI
ENC7O C7INI
B4 B3
- C0_S[1:0]
- C1_S[1:0]
- C2_S[1:0]
- C3_S[1:0]
- C4_S[1:0]
- C5_S[1:0]
- C6_S[1:0]
- C7_S[1:0]
-
B2 B1 B0
EC0I EC0T2SI EC0T1SI
EC1I EC1T2SI EC1T1SI
EC2I EC2T2SI EC2T1SI
EC3I EC3T2SI EC3T1SI
EC4I EC4T2SI EC4T1SI
EC5I EC5T2SI EC5T1SI
EC6I EC6T2SI EC6T1SI
EC7I EC7T2SI EC7T1SI
- 17 -
