9.1.1 Port Data Register (Px)

Symbol Address
P0 80H
P1 90H
P2 A0H
P3 B0H
P4 C0H
P5 C8H
P6 E8H
P7 F8H
Read and write port status
Write 0: Output low to port buffer.
Write 1: Output high to port buffer.
Read: Read the level on the port pin directly.

9.1.2 Ports Mode Registers (PxM0, PxM1)

Symbol Address
P0M0 94H
P0M1 93H
P1M0 92H
P1M1 91H
P2M0 96H
P2M1 95H
P3M0 B2H
P3M1 B1H
P4M0 B4H
P4M1 B3H
P5M0 CAH
P5M1 C9H
P6M0 CCH
P6M1 CBH
P7M0 E2H
P7M1 E1H
Configure the mode of the ports as shown below.
PnM1.x PnM0.x
0 0
0 1
1 0
1 1
Note: When an I/O port is selected as the ADC input channel, the PxM0/PxM1 register must be set to set the I/O port
mode to input mode. In addition, if the ADC channel still needs to be enabled after the MCU enters the power-down
mode/clock stop mode, you need to set the PxIE register to close the digital input to ensure that there will be no
additional power consumption.
