C1_S[1:0] : Enhanced PWM channel 1 output pin selection bit
C1_S[1:0] PWM1
00 P2.1
01 P1.1
10 P6.1
11 Reserved
C2_S[1:0] : Enhanced PWM channel 2 output pin selection bit
C2_S[1:0] PWM2
00 P2.2
01 P1.2
10 P6.2
11 Reserved
C3_S[1:0] : Enhanced PWM channel 3 output pin selection bit
C3_S[1:0] PWM3
00 P2.3
01 P1.3
10 P6.3
11 Reserved
C4_S[1:0] : Enhanced PWM channel 4 output pin selection bit
C4_S[1:0] PWM4
00 P2.4
01 P1.4
10 P6.4
11 Reserved
C5_S[1:0] : Enhanced PWM channel 5 output pin selection bit
C5_S[1:0] PWM5
00 P2.5
01 P1.5
10 P6.5
11 Reserved
C6_S[1:0] : Enhanced PWM channel 6 output pin selection bit
C6_S[1:0] PWM6
00 P2.6
01 P1.6
10 P6.6
11 Reserved
C7_S[1:0] : Enhanced PWM channel 7 output pin selection bit
C7_S[1:0] PWM7
00 P2.7
01 P1.7
10 P6.7
11 Reserved

19.2 Registers Related to PWM

Symbol Description
PWMSET Enhanced PWM Global Configuration Register
PWMCFG Enhanced PWM Configuration Register
Symbol Description
PWMCH PWM Counter High Byte
PWMCL PWM Counter Low Byte
PWMCKS PWM Clock Select Register
PWMTADCH PWM Trigger ADC Counter High Byte
PWMTADCL PWM Trigger ADC Counter Low Byte
Address
B7 B6 B5
F1H
- PWMRST -
F6H
- - -
Address
B7 B6 B5
FF00H -
FF01H
FF02H - - -
FF03H -
FF04H
Bit Address and Symbol
B4 B3 B2 B1
- - -
- PWMCBIF EPWMCBI ENPWMTA
Bit Address and Symbol
B4 B3 B2 B1
SELT2 PWM_PS[3:0]
Reset
B0 Value
x0xx,xxx0
- ENPWM
xxxx,0000
PWMCEN
Reset
Value
B0
x000,0000
0000,0000
xxx0,0000
x000,0000
0000,0000
