Xerox Wide Format 6705 System Manual page 91

077-900 Static Jam
077-901 Static Jam (Low Power Mode)
077-902 Static Jam (After Paper Output)
Reference BSD: CH8.2, CH8.4, CH8.5, CH8.6, CH8.7,
CH10.1, CH10.6, CH7.5
Note The MANUAL FEED STOP SENSOR does not detect
Static Jam when it has recovered from Low Power
Mode.
Check Items
• Check to see whether there is any remaining paper,
paper dust, or foreign substances on the paper transport
path.
• Check whether the voltage of the customer's power
supply and the +5V LVPS (5B) has fallen
• Check the following sensors for improper installation,
contamination, and foreign substances.
- ROLL 1 CUT TRIGGER SENSOR (PL10.4)
- ROLL 2 CUT TRIGGER SENSOR (PL10.4)
- RFC VERTICAL JAM SENSOR (PL10.3)
- MANUAL FEED STOP SENSOR (PL2.3)
- MANUAL PAGE SYNC SENSOR (PL2.4)
- RFC PAGE SYNC SENSOR (PL2.4)
- H-TRA JAM SENSOR (PL2.5)
- EXIT JAM SWITCH (PL7.4)
Procedure
Enter IOT DC330 [071-105].
Block the ROLL 1 CUT TRIGGER SENSOR by using a sheet
of blank paper.
Does the display of IOT DC330 [071-105] change from "H"
to "L"?
Y N
Go to the Reflective Sensor Failure FIP and check the
ROLL 1 CUT TRIGGER SENSOR (PL10.4).
Enter IOT DC330 [072-105].
Block the ROLL 2 CUT TRIGGER SENSOR by using a sheet
of blank paper.
Does the display of IOT DC330 [072-105] change from "H"
to "L"?
Y N
Go to the Reflective Sensor Failure FIP and check the
ROLL 2 CUT TRIGGER SENSOR (PL10.4).
A
2.3 2.3
Level 2 Troubleshooting
Chapter 2 Troubleshooting
A
Enter IOT DC330 [071-106].
Block the RFC VERTICAL JAM SENSOR by using a sheet of
blank paper.
Does the display of IOT DC330 [071-106] change from "H"
to "L"?
Y N
Go to the Reflective Sensor Failure FIP and check the
RFC VERTICAL JAM SENSOR (PL10.3).
Enter IOT DC330 [075-105].
Block the MANUAL FEED STOP SENSOR by using a sheet
of blank paper.
Does the display of IOT DC330 [075-105] change from "H"
to "L"?
Y N
Go to the Reflective Sensor Failure FIP and check the
MANUAL FEED STOP SENSOR (PL2.3).
Enter IOT DC330 [075-106].
Block the MANUAL PAGE SYNC SENSOR by using a sheet
of blank paper.
Does the display of IOT DC330 [075-106] change from "H"
to "L"?
Y N
Go to the Reflective Sensor Failure FIP and check the
MANUAL PAGE SYNC SENSOR (PL2.4).
Enter IOT DC330 [077-100].
Block the RFC PAGE SYNC SENSOR by using a sheet of
blank paper.
Does the display of IOT DC330 [077-100] change from "H"
to "L"?
Y N
Go to the Reflective Sensor Failure FIP and check the
RFC PAGE SYNC SENSOR (PL2.4).
Enter IOT DC330 [077-101].
Move the H-TRA JAM SENSOR Actuator manually to
block/clear the light path to the sensor.
Does the display of IOT DC330 [077-101] change between
"H" and "L"?
Y N
Go to the Permeable Sensor Failure FIP and check the
H-TRA JAM SENSOR (PL2.5).
B
B
Enter IOT DC330 [010-208].
Activate the EXIT JAM SWITCH Actuator and turn the switch
OFF then ON.
Does the display of IOT DC330 [010-208] change between
"H" and "L"?
("H": Paper detected/"L": Paper not detected)
Y N
Go to Switch (Normal Open) Fail FIP and check the
EXIT JAM SWITCH (PL7.4).
Replace the IOT PWB (PL8.1).
2-65
