UI Installation Kit
1. Hinge Assembly
2. Harness Guide
3. Left Hinge Cover
4. Right Hinge Cover
5. Post
6. UI Top Cover
7. Post Front Upper Cover
8. Post Front Lower Cover
9. Post Rear Cover
10. Clamp
11. Stylus Pen
12. Del TP Screw (M3x6) x4
13. TP Screw (M3x6) x3
14. TP Screw (M4x6) x3
15. Del TP Screw (M4x8) x3
(Figure 3) j0bn90003
8-4
WF6705 Kit-JPN (EB100387) (FX Only)
1. DVD-ROM
2. Utility Guide
3. Xerox Wide Format 6705 System MF Quick Guide
4. Xerox Wide Format 6705 System MF User Guide
(Figure 4) j0bn90004
WF6705 Kit ENG (EB100396) (AP/GCO Only)
1. DVD-ROM
2. Utility Guide x2
3. Safety Guide
(Figure 5) j0bn90006
