6.4.4 How to Enter and Exit the Diag Mode
6.4.4.1 How to Enter the Diag Mode
There are 3 ways to enter the Diag Mode as follows.
After Login, Directly Transition to Diag Mode
1. Press and hold the <0> key on the UI Panel for 3 seconds or longer and then press the
<Start> key, keeping your finger on the <0> key.
Note <0> + <Start> input is not accepted the following screen.
- Screen Brightness
- Tools (Setup)
- Job Status
- Machine Status
2. Enter the password '6789' using the Keypad and select [Enter].
Note The password entered will be displayed as ' **** '.
6-82
3. Select [DIAG Menu].
4. The system transitions to the Diag Mode and displays the Sub System Selection
screen.
5. Selecting a Sub System to diagnose displays the Diag Code Selection screen.
Note Selecting [DC132] performs the DC132 Machine ID/Billing Data.
(For more details, refer to [6.4.5 Diag Code Functions and Operation
Procedures])
