4. Remove the CP Control LVPS. (Figure 3)
Note Since the Wire Harness for the CP Cont Exhaust
Fan is installed directly to the CP Control LVPS,
do not disconnect the connector shown in the
blowout section in the following figure.
1) Disconnect the connector (x5).
2) Remove the screw (x4).
3) Remove the CP Control LVPS.
(Figure 3) j0bn40820
4.2 Disassembly/Assembly
Chapter 4 Disassembly/Assembly and Adjustment
Installation
Procedure
To install, carry out the removal steps in reverse order.
