Xerox Wide Format 6705 System Manual page 424

Chain-Link Item Name
(Color) Yellow Color Light Side - Maximum
710-715
Decrement Value
(Color) Yellow Color Dark Side - Maximum
710-716
Increment Value
(Color) Green Color Light Side - Maximum
710-717
Decrement Value
(Color) Green Color Dark Side - Maximum
710-718
Increment Value
(Color) Cyan Color Light Side - Maximum
710-719
Decrement Value
(Color) Cyan Color Dark Side - Maximum
710-720
Increment Value
(Color) Blue Color Light Side - Maximum
710-721
Decrement Value
(Color) Blue Color Dark Side - Maximum
710-722
Increment Value
(Color) Magenta Color Light Side -
710-723
Maximum Decrement Value
(Color) Magenta Color Dark Side -
710-724
Maximum Increment Value
(Color) Master Color Light Side - Minimum
710-725
Multiplication Value
(Color) Master Color Dark Side - Maximum
710-726
Multiplication Value
(Color) Gray Color Light Side - Minimum
710-727
Multiplication Value
6-44
Default Value Setting Range
168 0 to 255
64 0 to 255
48 0 to 255
64 0 to 255
48 0 to 255
64 0 to 255
52 0 to 255
64 0 to 255
72 0 to 255
64 0 to 255
10 0 to 255: 0 to 25.5
10 0 to 255: 0 to 25.5
10 0 to 255: 0 to 25.5
Contents
For how to set, refer to 710-709.
For how to set, refer to 710-710.
For how to set, refer to 710-709.
For how to set, refer to 710-710.
For how to set, refer to 710-709.
For how to set, refer to 710-710.
For how to set, refer to 710-709.
For how to set, refer to 710-710.
For how to set, refer to 710-709.
For how to set, refer to 710-710.
Sets the 0 to 2 (lightening side) from
among the 7 levels of UI Adjustment (0
to 6).
E.g.) Set 0
UI: 0 -> x 0.0 (settings value)
UI: 1 -> x 0.33 (equal distribution)
UI: 2 -> x 0.66 (equal distribution)
UI: 3 -> x 1.0 (default setting)
* UI 1 and 2 use equal
distribution.
Sets the 4 to 6 (darkening side) from
among the 7 levels of UI Adjustment (0
to 6).
E.g.) Set 40
UI: 3 -> x 1.0 (default setting)
UI: 4 -> x 2.0 (equal distribution)
UI: 5 -> x 3.0 (equal distribution)
UI: 6 -> x 4.0 (settings value)
* UI 4 and 5 use equal
distribution.
For how to set, refer to 710-725.
Remarks
6.3 Service Data
Chapter 6 General
