Xerox Wide Format 6705 System Manual page 623

A B
8.1 RFC 1 PAPER FEEDING
1
IOT PWB
DC330
PL8.1
ROLL 1 FEED MOTOR
J443
BIT 0 +5VDC
16
YEL
DC330
DC COM
ROLL 1 FEED MOTOR
BIT 1 +5VDC
17
YEL
DC COM
DC330
2
ROLL 1 FEED MOTOR
BIT 2 +5VDC
18
YEL
DC COM
3 NOTE:
1 Control of motor rotation is based on combinations of
signal outputs (Bit 0, Bit 1, Bit 2) from IOT PWB.
For details, see the table below.
Signal
Motor Status
BIT 2 BIT 1 BIT 0
H H H Stops immediately.
4
H H L Rotates in reverse.
H L H -
H L L -
L H H Rotates forward at low speed.
L H L Rotates forward at high speed.
L L H Slows down then stops.
L L L Slows down then holds.
5
2 The winding resistance of Motor is 6.4Ω±10% (25 ).
3
Virtual Line
7.1
6
7-93
C
RFC MOTOR PWB
PL8.5
071-001
+5VDC
1
J561
1
071-002
+5VDC DC COM
1
2
DC COM
071-003
+5VDC
1
DC COM
3
DC COM
+24VDC
(1.10 J2)
J443-9
(V)
DC COM
+5VDC
+2.2VDC
-
-
+2.2VDC
+2VDC
+5VDC
0VDC
℃
ROLL 1
FEED DRIVE
ZONE
H2
RFC 1 STACKED
PAPER
D E
ROLL 1 FEED MOTOR
J564 J661A
ON +24V CLOCK A
A1
1
BLU
CLOCK A
5 A3
BLU
CLOCK B
2 B1
BLU
CLOCK B
6 B3
BLU
A COM
3 A2
ORN
B COM
4 B2
ORN
071-270
DC330
ROLL 1 FEED MOTOR
J562 CLOCK +5VDC J443
1
Paper
ROLL 1 FEED
MOTOR
F G
ROLL 1 FEED
MOTOR
PL10.4
P661 P662 J662 P361
A1
1
BLU BRN
A3 5
BLU ORN
B1 2
BLU RED
B3 6
BLU YEL
A2 3
ORN BLK
B2 4
ORN WHT
IOT PWB
PL8.1
+5VDC
1
9
YEL
ROLL 1 FEED ROLL
H J
2
ROLL 1
FEED DRIVE
ZONE
MOT
D6
3
ROLL 1 FEED
MOTOR FAIL
8.8
SIGNAL
RFC 1 FED
8.2
PAPER
e0bnt730801
Chain 8 Paper Transportation
7.3 BSD
