2.5 Troubleshooting When CP-Cont is Started
2.5.1 Screen Numbers in UI Panel and CP-Cont Startup States
When CP-Cont is started, a progress bar and screen number are displayed in the UI Panel. This
screen number indicates a startup step of CP-Cont. When a failure such as CP-Cont not started
has occurred, the displayed or restarted screen number allows you to identify the step in which
the startup was stopped.
The following lists the screen numbers in UI Panel, CP-Cont states, systems that caused the
failure, and probable causes.
Stopped
Screen
No
Display
1/7 BIOS startup
2/7 OS basic service startup
3/7 OS service startup
4/7 Window system startup
2.5 Troubleshooting When CP-Cont is Started
Chapter 2 Troubleshooting
State
- Hardware
IPL
BOOT selector
OS boot
BIOS, BOOT, OS OS startup may have failed
OS startup
Device driver loading and device file
generation (udev)
HDD recovery (root file system)
Encrypted mapping
HDD recovery
File system mounting OS
Network setting
Time setting
Power control program
CWIS/SOAP/WebDAV service
startup
Service
SNPM/MIB service startup
Routing service startup
Diag startup check Diag startup
System That
Caused the Probable Cause
Failure
A hardware may have a failure
OS startup may have failed
A service startup may have failed
A special startup key-related failure
may have occurred
Action
Is the power turned ON?
No: Check the following:
AC input route, controller 24V input route, power switch
wiring route, WF01 PWB to Power Board wiring route,
and WF01 PWB to Motherboard wiring route
Yes: Check the following:
UI Panel signal connection route (UI Panel, UI Panel to
CP-Cont wiring route, WF02 PWB to Motherboard wiring
route, and WF02 PWB to WF01 PWB wiring route)
Refer to 2.5.2 "Identifying CP-Cont Errors
" to further identify the error of CP-Cont.
