010-331 Temp. Minimum Error (Thermistor 1)
Reference BSD: CH10.3 (100/120V), CH10.4 (200-240V),
CH10.5, CH10.8
Procedure
Go to 010-316 Low Temp. Thermistor 1 FIP.
010-332 Temp. Minimum Error (Thermistor 3)
Reference BSD: CH10.3 (100/120V), CH10.4 (200-240V),
CH10.5, CH10.8
Procedure
Go to 010-317 Low Temp. Thermistor 3 FIP.
2.3 2.3
Level 2 Troubleshooting
Chapter 2 Troubleshooting
010-970 Re-WarmUp Error
Reference BSD: CH10.5, CH10.8
Note Due to the machine performance, this error occurs
after continuous printing. When the machine has a
failure or this error occurs frequently, perform the
following procedures.
Procedure
Check IOT DC120 and IOT DC122 to see whether the
following Warm Up Time-out and Low Temp. Thermistor
errors have occurred.
- 010-316 Low Temp. Thermistor 1
- 010-317 Low Temp. Thermistor 3
- 010-322 Warm Up Time-out (Thermistor 1)
- 010-323 Warm Up Time-out (Thermistor 3)
Have the Warm Up Time-out and Low Temp. Thermistor
errors occurred?
Y N
Check if Warm Up transition temperature is set too high.
Go to the appropriate FIP.
042-312 USB Disconnected Error
Reference BSD: CH3.1, CH3.9
Procedure
Check the IOT USB CABLE (PL8.3) between the CP
CONTROL PWB J414 (LOWER) and the IOT PWB J451 for
open circuit and poor contact.
If no problems are found, replace the following parts in
sequence:
- IOT PWB (PL8.1)
- CP CONTROL PWB (PL8.6)
