Xerox Wide Format 6705 System Manual page 433

Chain-Link Settings Item
910-151 Inter-image for Paper/Roll 1
910-152 Inter-image for Paper/Roll 2
910-154 Inter-image for Paper/Bypass
910-155 Buzzer ON Timing When Setting Bypass
910-156 Pre-Feed Start Adjustment Time
910-201 Switch Image Control Settings
910-202 BTR T Switch Timing
910-203 BTR INT Switch Timing
910-204 DTS H1 ON Timing
910-205 DTS L1 Switch Timing/Roll Paper/Plain Paper
910-206 DTS L1 Switch Timing/Roll Paper/Tracing Paper
910-207 DTS L1 Switch Timing/Roll Paper/Transparency
910-208 DTS L1 Switch Timing/Cut Paper/Plain Paper
910-209 DTS L1 Switch Timing/Cut Paper/Tracing Paper
910-210 DTS L1 Switch Timing/Cut Paper/Transparency
910-211 DTS L2 Switch Timing/Roll Paper/Plain Paper
910-212 DTS L2 Switch Timing/Roll Paper/Tracing Paper
910-213 DTS L2 Switch Timing/Roll Paper/Transparency
910-214 DTS L2 Switch Timing/Cut Paper/Plain Paper
910-215 DTS L2 Switch Timing/Cut Paper/Tracing Paper
910-216 DTS L2 Switch Timing/Cut Paper/Transparency
910-217 DTS H2 Switch Timing/Roll Paper/Plain Paper
910-218 DTS H2 Switch Timing/Roll Paper/Tracing Paper
910-219 DTS H2 Switch Timing/Roll Paper/Transparency
910-220 DTS H2 Switch Timing/Cut Paper/Plain Paper
910-221 DTS H2 Switch Timing/Cut Paper/Tracing Paper
910-222 DTS H2 Switch Timing/Cut Paper/Transparency
910-223 DTS INT Switch Timing
910-224 BCR Temperature Threshold Value
910-225 BCR AC/Normal Temperature
910-226 BCR AC/Low Temperature
910-227 BCR DC
910-228 Deve Bias AC
910-229 Deve Bias DC 1
910-230 Deve Bias DC 2
910-231 Deve Bias DC 3
910-232 Deve Bias DC 4
910-233 Deve Bias DC 5
910-234 Deve Bias DC Humidity Correction/Reference Value
6.3 Service Data
Chapter 6 General
Default Value Setting
Sub
Range
JPN AP GCO
RFC 149 149 149 50 to 200
RFC 149 149 149 50 to 200
Bypass 150 150 150 50 to 200
Bypass 22 22 22 0 to 50
Bypass 19 19 19 0 to 50
Image 1 1 1
XERO -5 -5 -5 -50 to 50
XERO -10 -10 -10 -50 to 50
XERO -20 -20 -20 -150 to 50
XERO 50 50 50 -50 to 350
XERO 220 220 220 -50 to 350
XERO 50 50 50 -50 to 350
XERO 50 50 50 -50 to 350
XERO 220 220 220 -50 to 350
XERO 50 50 50 -50 to 350
XERO -33 -33 -33 -150 to 100
XERO -33 -33 -33 -150 to 100
XERO -37 -37 -37 -150 to 100
XERO -33 -33 -33 -150 to 100
XERO -33 -33 -33 -150 to 100
XERO -37 -37 -37 -150 to 100
XERO -10 -10 -10 -150 to 100
XERO -10 -10 -10 -150 to 100
XERO -10 -10 -10 -150 to 100
XERO -10 -10 -10 -150 to 100
XERO -10 -10 -10 -150 to 100
XERO -10 -10 -10 -150 to 100
XERO 20 20 20 -50 to 150
XERO 15 15 15 0 to 30
XERO 150 150 150 70 to 380
XERO 170 170 170 70 to 380
XERO 400 400 400 206 to 644
XERO 700 700 700 438 to 1063
XERO 300 300 300 50 to 550
XERO 300 300 300 50 to 550
XERO 300 300 300 50 to 550
XERO 300 300 300 50 to 550
XERO 300 300 300 50 to 550
XERO 15 15 15 5 to 95
Change
Amount
10 ms
10 ms
10 ms
100 ms
100 ms
0, 1 -
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
10 ms
1 degree C
0.01 mA
0.01 mA
-1VDC
1V AC
-1VDC
-1VDC
-1VDC
-1VDC
-1VDC
Humidity based on the standard for humidity
1%
correction
Setting Data DC951
BCR
BCR
BCR
Deve Bias
Deve Bias
Deve Bias
Deve Bias
Deve Bias
Deve Bias
6-53
