Xerox Wide Format 6705 System Manual page 412

Chain-Link Item Name
CIS Position Adjustment -
Slow Scan Position
710-373
Adjustment Upper Limit during
Fast Scan Adjustment
CIS Position Adjustment -
Line Pitch Tolerance Upper
710-374
Limit during Slow Scan
Adjustment
CIS Position Adjustment -
Slow Scan Position
710-375
Adjustment Upper Limit during
Slow Scan Adjustment
CIS Position Adjustment -
710-376 Pattern Search Width during
Fast Scan Adjustment
CIS Position Adjustment -
710-377 Pattern Search Height during
Fast Scan Adjustment
CIS Position Adjustment -
710-378 Pattern Search Width during
Slow Scan Adjustment
CIS Position Adjustment -
710-379 Pattern Search Height during
Slow Scan Adjustment
CIS Position Adjustment -
Fast Scan Position
710-380
Adjustment Determination
Margin
CIS Position Adjustment -
Slow Scan Position
710-381
Adjustment Determination
Margin
6-32
Default Value Setting Range
h'10
0 to 32 lines
(= 16 lines)
h'8
0 to 32 lines
(= 8 lines)
h'10
0 to 32 lines
(= 16 lines)
h'60
8 to 255 dot
(= 96 dot)
h'24
8 to 72 lines
(= 36 lines)
h'60
8 to 96 dot
(= 96 dot)
h'10
8 to 72 lines
(= 16 lines)
h'2
0 to 32 dot
(= 2 dot)
h'2
0 to 32 lines
(= 2 lines)
Contents
Specifies the limit for the Slow Scan Position Adjustment
value that is calculated in the CIS Position Adjustment
Pattern Scan.
If the calculated Slow Scan Position Adjustment value
has exceeded the limit, it becomes a CIS Position
Adjustment Error.
Specifies the limit of misregistration between horizontal
lines for the CIS Position Adjustment Document that is
used in the CIS Position Adjustment Pattern Scan.
If the misregistration that was determined from the
pattern has exceeded the limit, it becomes a CIS Position
Adjustment Error.
Specifies the limit for the Slow Scan Position Adjustment
value that is calculated in the CIS Position Adjustment
Pattern Scan.
If the calculated Slow Scan Position Adjustment value
has exceeded the limit, it becomes a CIS Position
Adjustment Error.
Specifies the Fast Scan Width when searching the
pattern at Fast Scan Position Adjustment of CIS Position
Adjustment Pattern Scan.
Specifies the Slow Scan Width when searching the
pattern at Fast Scan Position Adjustment of CIS Position
Adjustment Pattern Scan.
Specifies the Fast Scan Width when searching the
pattern at Slow Scan Position Adjustment of CIS Position
Adjustment Pattern Scan.
Specifies the Slow Scan Width when searching the
pattern at Slow Scan Position Adjustment of CIS Position
Adjustment Pattern Scan.
Specifies the determination margin for the Fast Scan
Position Adjustment value of CIS Position Adjustment
Pattern Scan.
If the Fast Scan Position Adjustment has exceeded the
value by +/-margin at the determination, it becomes an
Adjustment Value Determination Error.
Specifies the determination margin for the Slow Scan
Position Adjustment value of CIS Position Adjustment
Pattern Scan.
If the Slow Scan Position Adjustment has exceeded the
value by +/-margin at the determination, it becomes an
Adjustment Value Determination Error.
Remarks
