CPS COLOR COROB D200 Technical Manual page 89

M1
Stepper Motor
GR PHA
GR/WH /PHA
RD/WH PHB
RD /PHB
COROB S.p.a. TITLE of SHEET:
Via dell'Agricoltura, 3
BANCO CABLING
41038 S. Felice s/P (MODENA)
ITALY
DWG no.:
BANCO.dsn
0033500
J2.5
J4
GR 1
2
GR/WH
3
RD/WH
4
RD
SAPS (Canister Stirring Pump Stepper) Connection - Simultaneous Version
SH5
CBSLAVE - COROB
J3
J2
J1
J3.5
0036100
CAF1
M
MA1
Stirring motor
Date: Tuesday, November 16, 1999
Diagram 5
Sheet no.:
CAGE Code: Benatti Fabrizio Revision :
4.A
of : ....
V 1.0
