CPS COLOR COROB D200 Technical Manual page 39

3.9.1 Connectors
Connectors Type
JIN input
JMOT output
J3 input
J4 input
J5 input
input
J6
output
Version 1.0 - rev0 - May 2006
Description
power supply (+24V) from CBShelf
power supply (+24V) to shelf motor
from shelf SAFETY button
from shelf UP button
from shelf DOWN button
power supply (+24V) from CBShelf
signal from buttons SAFETY, UP, DOWN and RELAY STATUS to CBShelf
3-21
