3.9 CBSafe
The CBSafe board is present only when the dispenser is equipped with semiautomatic shelf.
Connectors
JIN
J3 ÷ J5
J6
Pin-outs
pin 1
pin 2
pin 1
pin 3
on the machine
pin 1
pin 2 ÷ 5
pin 6
COROB™ AUTOMATIC DISPENSERS
Value
+24V
ground
+24V
signal
Ground
+24V
signal
ground
