Connectors

J4 - J13
J18 - J21 - J29
J103
3.2.1 Connectors
Connectors Type
J4 input
J13 input
J17 input
J18 output
J21 output
J26 serial
J27 serial
J28 serial
J29 output
J103 input

3.2.2 Indicator LEDs

LED Status Description
ON +5V present
D3
OFF +5V not present
ON Cap open position
D4
OFF Cap close position
D6 ON +24V present
Description
Off-line button
Open cap sensor
Power supplies +5V, +24V
Off-line button lamp
Humidifier motor
RS485, internal
RS232, external
USB
RS232, external
Automatic sliding cap
Humidity / Temperature sensor
Pin-outs
pin 1
pin 2
pin 3
pin 4
pin 1
pin 2
pin 1
pin 2
pin 3
pin 4
Notes
if device is present
sliding cap
+5V to power the logic, and +24V to power the external
PNP sensors of the board
if device is present
if device is present
as an option to RS232 (only for CBMaster_E version)
(only for CBMaster version lower than CBMaster_E)
if humidifier device is present - only for CBMaster_E
version
Relevant component / Notes
present only for CBMaster version
COROB™ AUTOMATIC DISPENSERS
Value
+24V
+24V
signal
ground
+24V
ground
ground
signal
signal
+5V
lower than CBMaster_E
