3 CONTROL ELECTRONICS

3.1 Introduction

COROB™ automatic dispensers are managed and operated via a a dispensing application software installed
on the management computer.
The management computer sends high level commands to the machine firmware installed in the different
control boards.
The presence of some electronic boards depend on the type of dispensing circuits and optional the machine
is equipped with.
In the following table, there is an overview of possible combinations:
Board name Description
CBMaster CPU board
CBMono Power distribution board
CBMB Power distribution board
CBModule SAPS control board
CBSlave SAPS control board
CBShelf Board for the management of the Semiautomatic shelf
CBSafe Safety board for the control buttons of the
Semiautomatic shelf
CBLaser Board for the management of the Bung Hole Locator
laser
Version 1.0 - rev0 - May 2006
Sequential Simultaneous
machine machine
•
•
•
Additional board
Additional board
Additional board
3-3
•
•
•
