CPS COLOR COROB D200 Technical Manual page 83

SP1
To 110/230V AC
1 L
2 0035300
PE
Mono-Phase Line
3 N
L3
N3
INT1
L1
N1
IPE1
IL1
N2
L2
PE
PE5
CONTROL PANEL
COROB S.p.a. TITLE of SHEET:
Via dell'Agricoltura, 3
BANCO CABLING
41038 S. Felice s/P (MODENA)
ITALY
DWG no.:
FL1
PS1
L1
L L
Pe
PE
N N
N1
CM1 CF1
N1 1 1 N1
2 2
L1 3 3
L1
N2 4 4 N2
PE
5 5 PE
L2 6 6 L2
N3
7 7 N3
8 8
L3 9 9 L3
Cal4
PS2 L
L3
Pe PE
0035000
N N3
PS3
L L3
Pe PE
N N3
PS4 L
L3
Pe PE
N N3
Power Supply Connection - Simultaneous / Sequential Version
BANCO.dsn
Legenda - Wiring 0034900
N1, N2, N3 - Blue -
L1, L2, L3 - Black - Phase
PE - Yellow/Green -
PE1
0034900
Panel Wiring
PE3
PE2
Date: Tuesday, November 16, 1999
Diagram 1
Neutral
Earth
AL1
16
P1
14
BU
N2 1 GY 12
L2 2 GY 10
3 BK 8
4 WH 6
4
WH
2
Legenda - Cable 0034200
WH - White +42V
RD - Red +24V
BK - Black GND
GY - Gray GND
BU - Blue GND
OR - Orange +5V
16
BU 14
GY 12
GY 10
BK 8
6
WH
WH 4
2
To J5 connector for the simultaneous Version (page 3.A)
or to J100 connector for the sequential Version (page 3.C)
CAGE Code: Benatti Fabrizio
P2
15 OR
13
OR
11 GY
9 GY
7 RD
5 WH
3
WH
1
0034200
J5
15
OR
13 OR
11 GY
9 GY
7 RD
5
WH
3 WH
1
Sheet no.: 1
of : ....
Revision : V 1.0
