Connectors

J1
J5 ÷ J20
CNM1 ÷ CNM3
3.8.1 Connectors
Connectors Type
J1 output
J5 output
J10 input/output
J11 input/output
J12 input/output
J13 input/output
J14 input
J15 input
J16 input
J17 input/output
J18 input/output
J19 input/output
J20 input/output
J23 input
J26 input
J27 input/output
CNM1 output
CNM3 output
Version 1.0 - rev0 - May 2006
pin 1
pin 2
pin 1
pin 2
pin 3
pin 4
pin 1
pin 2
Description
power supply to punching lamp
power supply to can presence photocell
cap free sensor
cap closed sensor
cap open sensor
power supply to CBSafe and to shelf SAFETY button
shelf UP button
shelf DOWN button
status of relays on CBSafe
can presence photocell
punching sensor
shelf upper position sensor
shelf lower position sensor
firmware programming
power supply input from CBMB (when at least one parallel circuit is
present) or CBMono
RS485 line, from CBMaster
power supply to cap motor
power supply to shelf motor
Pin-outs
+24V
ground
+24V
+24V
signal
ground
+24V
ground
3-17
Value
Notes
with punch
with punch
with punch
